X-HOUSE PRO
Standing single-phase high-voltage mix-grid All-in-one syste
Capacity:10kWh - 30kWh
Output Power Of inverter:5kW - 10kW
Max. Input Voltage :600V
Protection Level:IP66
Weight:113 KG
Size:
584x1009x193 mm
Parallel Installation:
Support parallel for on/off grid (Max.10 units for on-grid system/ Max.3 units for off-grid system)
X-HOUSE
Standing single-phase low-voltage hybrid grid All-in-one
Capacity:8.5-16.896 kWh
Rated Power:5-6.5KW
MAX.PV Input Power:9000W
AC Input:220V Vac；
L+N+PE；50/60 Hz
Protection Level:IP 21
Weight:≤65kg - ≤90kg
Size:
650mm×450mm×850mm（±5mm）
700mm×500mm×900mm（±5mm）
X-HOME
Low-voltage off-grid stacked All-in-one
Capacity：15 kWh
Rated power:6.2 kW / 10.2 kW
Net weight(kg):113Kg±1Kg
IP protection:IP 20
Net weight(kg):113Kg±1Kg
Battery Size:700*500*267.2mm
AC voltage(Battery mode)(220VAC～240VAC)±5%,230VAC(Default value)
Max of Battery packs:4
X-Inverter
Low-voltage single-phase/three-phase off-grid
Max Input Power：8000-18000w
Output Power：5-12kw
Voltage：120-800V
Weight：14-59KG
Number of MPPT：2-4
Protection Level：IP21/54/65
Size：
360*470*114mm
465*665*165mm
X-Battery
Low Voltage Battery
Capacity：5.15-14.34 kWh
Voltage：51.2V
Weight：48-120KG
Protection Level：IP21/54/65
Size：
480*465*152mm
450*246*844mm
